Samuel SCD Series
The SCD features rugged structural steel frame construction which will withstand the demands of any plant environment. With a high torque 3 phase AC gear motor drive, and a high capacity linear bearing on the mandrel drive, this jumbo dispenser will deliver strap evenly to your unitizing equipment. UL and CSA approved electrics can be combined with your systems’ shut off switch for maximum safety for plant personnel.
Model SCD12, SCD14, and SCD15 - Versatile Jumbo Steel Coil Dispensers
- Large capacity strap accumulation tower
- Jib Crane (depending on model)
- Up to 2000 lbs capacity (depending on model)
- 3 Phase gear motor drive
- Eliminates strap tangle
- Positive vertical strap
- Expandable mandrel on SCD15 for easier strap loading
- SCD12 - 100lbs capacity (50 kg)
- SCD14 - 1000lbs capacity (500 kg)
- SCD15 - 2000lbs capacity (1000 kg)
| Voltage: | 480 3 Phrase/575 3 Phase |
|---|---|
| Current: | 10 Amps |
| Max Coil Weight: | up to 2000lbs (900 kg) (depending on model) |
| Max Coil O.D.: | 36" (914mm) |
| Min Coil I.D.: | 16" (406mm) |
| Max Rotation Speed at 60Hz: | 22 RPM |
| Recommended Jog Speed at 20Hz: | 7 RPM |
| Feed Rate at 36" Coil O.D.: | 207 FPM (63 M/min) |
| Feed Rate at 30" Coil O.D.: | 172 FPM (52 M/min) |
| Feed Rate at 16" Coil I.D.: | 92 FPM (28 M/min) |
| Max Tower Capacity: | 37'8" (11.5m) |
